Details
Form Factor M.2 2280
Capacity 1TB
Interface PCIe Gen 4.0 x4 NVMe 1.4
Performance
Max Sequential Read Up to 7000 MBps
Max Sequential Write Up to 5500 MBps
4KB Random Read Up to 650,000 IOPS
4KB Random Write Up to 700,000 IOPS
Terabytes Written (TBW) 700TB
MTBF 3,000,000 hours
HeatSink Aluminum and graphene heat sink
Features
Features Enjoy the lightning speed of the PCIe Gen4 x4
Featuring two patented heat sinks
Effective cooling - flexible installation
Supports the latest NVMe 1.4 standard
Environmental
Operating Temperature 0??C ~ +70??C
Storage Temperature -40??C ~ +85??C
Operating Humidity RH 90% under 40??C
Max Shock Resistance 1,500G/0.5ms
Max Vibration Resistance 80Hz~2,000Hz/20G
Dimensions & Weight
Height 12.90mm (with Aluminum heat sink)
3.70mm (with Graphene heat sink)
Width 22.00mm (with Aluminum heat sink)
23.40mm (with Graphene heat sink)
Depth 80.00mm
Weight 0.46 oz (with Graphene heat sink)
1.62 oz (with Aluminum heat sink)
