Netgear AV Line M4250-10G2F-PoE+ (GSM4212P) 8x1G PoE+ 125W 2x1G and 2xSFP Managed Switch
Groundbreaking AV GUI
A simplified user interface makes it easy to assign configuration profiles to each port.
Multicast in an Instant
NETGEAR IGMP Plus provides multicast functionality right out of the box for most AV over IP applications.
Sleek, Quiet Design
Less fan noise, and mounting ears included for under-table or wall mounting.
Automatic Configuration
Auto-trunk and auto-LAG functionality auto connects with other M4250 (and M4300) switches.
The Netgear GSM4212P-100AJS is a powerful and versatile managed switch ideal for small to medium-sized businesses and demanding network environments. This switch offers eight Gigabit Ethernet ports with Power over Ethernet Plus (PoE+) capability, providing up to 30W of power per port, totaling 125W. This makes it perfect for powering devices such as VoIP phones, IP cameras, and wireless access points without the need for separate power adapters. In addition to the PoE+ ports, the GSM4212P-100AJS also features two dedicated Gigabit Ethernet uplink ports and two SFP ports for fiber connectivity, providing flexibility for network expansion and high-bandwidth applications. The managed functionality allows for advanced control and configuration options, including VLANs, QoS, and port mirroring, ensuring optimal network performance and security. This switch is designed for reliable operation and includes features like automatic denial-of-service (DoS) prevention and advanced Layer 2 switching capabilities. The intuitive web-based interface simplifies management and monitoring, making it easy to configure and maintain your network. The Netgear GSM4212P-100AJS is a robust and comprehensive solution for businesses looking to deploy a secure and high-performance network infrastructure. Its compact design and comprehensive feature set make it a cost-effective choice for powering and managing a variety of network devices.
Features
- 8 Gigabit Ethernet PoE+ ports delivering up to 30W per port.
- Total PoE budget of 125W, enabling powering of multiple devices.
- 2 dedicated Gigabit Ethernet uplink ports for non-PoE devices or network connections.
- 2 dedicated SFP ports for fiber optic connectivity, providing high-speed and long-distance networking options.
- Advanced Layer 2 management features, including VLANs, QoS, and port mirroring.
- VLAN support allows for network segmentation, improving security and performance.
- Quality of Service (QoS) prioritises critical network traffic, ensuring optimal performance for VoIP and video streaming.
- Port mirroring enables network traffic monitoring and analysis for troubleshooting and security.
- Web-based management interface for easy configuration and monitoring.
- SNMP support for remote monitoring and management via network management systems.
- Compact and fanless design for quiet operation and space-saving installation.
- Durable metal enclosure for enhanced protection in demanding environments.
- Energy-efficient design reduces power consumption and operating costs.
- IEEE 802.3af/at (PoE/PoE+) compliant, ensuring compatibility with a wide range of powered devices.
- Auto-MDI/MDIX eliminates the need for crossover cables, simplifying network setup.
- Loop detection prevents network loops and ensures network stability.
- Storm control protects against broadcast, multicast, and unknown unicast storms.
- IGMP snooping optimises multicast traffic delivery for efficient use of network bandwidth.
- Supports jumbo frames for improved performance in data-intensive applications.
- Limited Lifetime Warranty provides peace of mind and protection against defects.
- Ideal for powering and connecting IP cameras, VoIP phones, wireless access points, and other PoE-enabled devices.
- Suitable for small to medium-sized businesses, offices, and surveillance deployments.
Physical Specifications
Dimensions (WxDxH): 440 x 200 x 43.2mm
Weight: 2.85Kg (6.28lb)
Technical Specs
Primary Port Speed: 1 Gigabit
Number of Ports: 12 (10x 1G, 2x SFP)
PoE Ports / Budget: 8 PoE+ (30W/port), 125W Budget
IGMP Support: Enhanced (NETGEAR IGMP Plus)
Jumbo Frame Support: Yes, up to 12kb
Acoustics: Fanless or 30dB @ 25°C
Power Consumption
With PoE: 163.9W/559.555Btu/hr
Without PoE: 17.32W/59.13Btu/hr
Standby without any port connection: 8.53W/29.121Btu/hr
AVB Support: Yes. Electronic license required, activation key sent via email (AVB4212P-10000S)
Third party support: Domotz
What's in the Box
M4250-10G2F-PoE+ (GSM4212P)
Power cord(s)
Console USB Type-C and RJ45-DB9 cables
Rack-mounting standard brackets
Longer brackets for recessed mounting
Rubber footpads for tabletop installation
Installation Guide
SUPPORT & WARRANTY
Warranty: This product is backed by a NETGEAR ProSAFE ® Limited Lifetime Hardware Warranty.
This product comes with a limited warranty that is valid only if purchased from a NETGEAR authorised reseller, and covers unmodified hardware, fans and internal power supplies – not software or external power supplies, and requires product registration
at https://www.netgear.com/business/registration within 90 days of purchase; see https://www.netgear.com/about/warranty for details. Intended for indoor use only.
Support: Phone and chat technical support provided for 90 days from purchase date.
Warranty: 12 Months*
*Warranty period is as stated above unless the manufacturer has chosen to specify a longer period. All warranties are return to base unless otherwise specified.
