Features
Kingston FURY KF560C30BBEK2-32 is a kit of two 2G x 64-bit (16GB) DDR5-6000 CL30 SDRAM (Synchronous DRAM) 1Rx8, memory module, based on eight 2G x 8-bit FBGA components per module. Each module kit supports AMD® EXPO v1.1 and Intel® Extreme Memory Profiles (Intel® XMP) 3.0. Total kit capacity is 32GB. Each module has been tested to run at DDR5-6000 at a low latency timing of 30-36-36 at 1.4V. The SPDs are programmed to JEDEC standard latency DDR5-4800 timing of 40-39-39 at 1.1V. Each 288-pin DIMM uses gold contact fingers. The JEDEC standard electrical and mechanical specifications are as follows:
FACTORY TIMING PARAMETERS
Default (JEDEC): DDR5-4800 CL40-39-39 @1.1V
EXPO Profile #0: DDR5-6000 CL30-36-36 @1.4V
EXPO Profile #1: DDR5-5600 CL40-40-40 @1.25V
XMP Profile #1: DDR5-6000 CL30-36-36 @1.4V
XMP Profile #2: DDR5-5600 CL40-40-40 @1.25V
Power Supply
VDD = 1.1V Typical
VDDQ = 1.1V Typical
VPP = 1.8V Typical
VDDSPD = 1.8V to 2.0V
On-Die ECC
Height 1.37" (34.9mm), with heatsink
Up to 6000 MHz speed for playing the latest games and using heavy software
DIMM 32 GB of memory can produce approx. 10K MIPS and as a result, your system gets more room to run complex apps.
With DDR5 SDRAM get efficient data transfer rate and enhanced computer's performance
Whether you are playing games, using heavy loaded OS or video editing software, the DIMM 32GB of memory will make them run in a flash.
- Improved stability for overclocking, increased efficiency
- Intel XMP 3.0-Ready and Certified
- Qualified by the world's leading motherboard manufacturers
- Low-profile heat spreader design
Specifications
Brand: Kingston
Series: Kingston FURY Beast DDR5
Memory Size: 32 GB (2x16GB)
Memory Speed: 6000 MT/s
Product Type: RAM Module
Manufacturer Part Number: KF560C30BBEK2-32
Manufacturer: Kingston
Dimensions: 13.34 x 0.66 x 3.48 cm
Weight: 37g
Colour: Black
Memory Type: DDR5 SDRAM
Number of Pins: 288-Pin
Form Factor: DIMM
Voltage: 1.35 Volts
Item Weight: 37g
Compatible Devices: Desktop
Warranty: 12 Months*
