Essentials
Product Collection: 12th Generation Intel Core i7 Processors
Code Name: Products formerly Alder Lake
Vertical Segment: Desktop
Processor Number: i7-12700
Lithography: Intel 7
CPU Specifications
Total Cores: 12
Number of Performance-Cores: 8
Number of Efficient-Cores: 4
Total Threads: 20
Max Turbo Frequency: 4.90 GHz
Intel Turbo Boost Max Technology 3.0 Frequency: 4.90 GHz
Performance-Core Max Turbo Frequency: 4.80 GHz
Performance-Core Base Frequency: 2.10 GHz
Efficient-Core Max Turbo Frequency: 3.60 GHz
Efficient-Core Base Frequency: 1.60 GHz
Cache: 25 MB Intel Smart Cache
Total L2 Cache: 12 MB
Processor Base Power: 65 W
Maximum Turbo Power: 180 W
Memory Specifications
Max Memory Size (dependent on memory type): 128 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max Number of Memory Channels: 2
Max Memory Bandwidth: 76.8 GB/s
Processor Graphics
Processor Graphics: Intel UHD Graphics 770
Graphics Base Frequency: 300 MHz
Graphics Max Dynamic Frequency: 1.50 GHz
Graphics Output: eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units: 32
Max Resolution (HDMI): 4096 x 2160 @ 60Hz
Max Resolution (DP): 7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel): 5120 x 3200 @ 120Hz
DirectX Support: 12
OpenGL Support: 4.5
Multi-Format Codec Engines: 2
Intel Quick Sync Video: Yes
Intel Clear Video HD Technology: Yes
Number of Displays Supported: 4
Device ID: 0x4680
OpenCL Support: 2.1
Expansion Options
Direct Media Interface (DMI) Revision: 4.0
Max Number of DMI Lanes: 8
Scalability: 1S Only
PCI Express Revision: 5.0 and 4.0
PCI Express Configurations: Up to 1x16+4, 2x8+4
Max Number of PCI Express Lanes: 20
Package Specifications
Max CPU Configuration: 1
Supported Sockets: FC-LGA1700
Thermal Solution Specification: PCG 2020C
T Junction (Temperature Junction Max): 100°C
Package Size: 45.0 mm x 37.5 mm
Advanced Technologies
Intel Gaussian & Neural Accelerator: 3.0
Intel Thread Director: Yes
Intel Deep Learning Boost (Intel DL Boost): Yes
Intel Optane Memory Supported: Yes
Intel Speed Shift Technology: Yes
Intel Turbo Boost Max Technology 3.0: Yes
Intel Turbo Boost Technology: 2.0
Intel Hyper-Threading Technology: Yes
Intel Virtualization Technology (VT-x): Yes
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel 64: Yes
Instruction Set: 64-bit
Instruction Set Extensions: Intel SSE4.1, Intel SSE4.2, Intel AVX2
Idle States: Yes
Enhanced Intel SpeedStep Technology: Yes
Thermal Monitoring Technologies: Yes
Intel Volume Management Device (VMD): Yes
Security & Reliability
Intel AES New Instructions: Yes
Secure Key: Yes
Intel OS Guard: Yes
Execute Disable Bit: Yes
Intel Boot Guard: Yes
Mode-based Execute Control (MBE): Yes
Intel Control-Flow Enforcement Technology: Yes
Warranty: 36 Months*
