IE340 Series
Industrial Ethernet Gigabit Layer 3 Switches with PoE+
Ruggedized switches built to provide enduring performance in harsh environments, such as manufacturing, transportation and physical security. IE340 switches deliver Power over Ethernet (PoE+) with the performance and reliability demanded by deployments in the age of the Internet of Things (IoT).
Overview
- Offering high throughput, rich functionality and advanced security features
- Ruggedized to meet the latest industrial Ethernet standards for temperature, vibration and electrical noise
- Support highly stable and reliable network switching, with a recovery time of less than 50ms
- Superior security including SSL, SSH, 802.1X, MAC, IP filtering, RADIUS, TACACS+ and VLAN
- Device management through Web GUI, SNMP, Telnet, SSH or Allied Telesis Autonomous Management Framework Plus (AMF Plus)
Key Features
- AlliedWare Plus feature-rich operating system
- Autonomous Management Framework Plus (AMF Plus) node
- OpenFlow for SDN
- Active Fiber Monitoring (AFM) detects and prevents attempts to tamper with fiber links
- Industrial automation protocol support (Modbus/TCP)
- Ethernet Protection Switched Ring (EPSRing)
- Ethernet Ring Protection Switching (ITU-T G.8032)
- Routing capability (ECMP, OSPF, RIP, Static and BGP)
- Upstream Forwarding Only (UFO)
- Precise time synchronization(IEEE 1588 PTP)
- IEEE 802.3at PoE+ sourcing (30W)
- Dynamic PoE power allocation
- Continuous PoE ensures endpoint uptime, even during a switch firmware upgrade
- Enhanced Thermal Shutdown
- Redundant power inputs
- Alarm input and output ports
- Fanless design for high-reliability and silent operation
