Essentials
Product Collection
12th Generation Intel?? Core??? i5 Processors
Code Name
Products formerly Alder Lake
Vertical Segment
Desktop
Processor Number
i5-12400
Status
Launched
Launch Date
Q1'22
Lithography
Intel 7
CPU Specifications
Total Cores
6
# of Performance-cores
6
# of Efficient-cores
0
Total Threads
12
Max Turbo Frequency
4.40 GHz
Performance-core Max Turbo Frequency
4.40 GHz
Performance-core Base Frequency
2.50 GHz
Cache
18 MB Intel?? Smart Cache
Total L2 Cache
7.5 MB
Processor Base Power
65 W
Maximum Turbo Power
117 W
Memory Specifications
Max Memory Size (dependent on memory type)
128 GB
Memory Types
Up to DDR5 4800 MT/s
Up to DDR4 3200 MT/s
Max # of Memory Channels
2
Max Memory Bandwidth
76.8 GB/s
Processor Graphics
Processor Graphics*
Intel?? UHD Graphics 730
Graphics Base Frequency
300 MHz
Graphics Max Dynamic Frequency
1.45 GHz
Graphics Output
eDP 1.4b, DP 1.4a, HDMI 2.1
Execution Units
24
Max Resolution (HDMI)*
4096 x 2160 @ 60Hz
Max Resolution (DP)*
7680 x 4320 @ 60Hz
Max Resolution (eDP - Integrated Flat Panel)*
5120 x 3200 @ 120Hz
DirectX Support
12
OpenGL Support
4.5
Multi-Format Codec Engines
1
Intel?? Quick Sync Video
Yes
Intel?? Clear Video HD Technology
Yes
# of Displays Supported*
4
Device ID
0x4692 / 0x4682
OpenCL Support
2.1
Expansion Options
Direct Media Interface (DMI) Revision
4.0
Max # of DMI Lanes
8
Scalability
1S Only
PCI Express Revision
5.0 and 4.0
PCI Express Configurations*
Up to 1x16+4, 2x8+4
Max # of PCI Express Lanes
20
Package Specifications
Max CPU Configuration
1
Thermal Solution Specification
PCG 2020C
T JUNCTION
100??C
Package Size
45.0 mm x 37.5 mm
Advanced Technologies
Intel?? Gaussian & Neural Accelerator
3.0
Intel?? Thread Director
No
Intel?? Deep Learning Boost (Intel?? DL Boost)
Yes
Intel?? Optane??? Memory Supported*
Yes
Intel?? Speed Shift Technology
Yes
Intel?? Turbo Boost Max Technology 3.0*
No
Intel?? Turbo Boost Technology*
2.0
Intel?? Hyper-Threading Technology*
Yes
Intel?? Virtualization Technology (VT-x)*
Yes
Intel?? Virtualization Technology for Directed I/O (VT-d)*
Yes
Intel?? VT-x with Extended Page Tables (EPT)*
Yes
Intel?? 64*
Yes
Instruction Set
64-bit
Instruction Set Extensions
Intel?? SSE4.1, Intel?? SSE4.2, Intel?? AVX2
Idle States
Yes
Enhanced Intel SpeedStep?? Technology
Yes
Thermal Monitoring Technologies
Yes
Intel?? Volume Management Device (VMD)
Yes
Security & Reliability
Intel?? AES New Instructions
Yes
Secure Key
Yes
Intel?? OS Guard
Yes
Execute Disable Bit*
Yes
Intel?? Boot Guard
Yes
Mode-based Execute Control (MBE)
Yes
Intel?? Control-Flow Enforcement Technology
Yes
